Additional information
| Function | Temperature control of the superheated steam |
|---|---|
| Diameters | Water: 1″ – 1½” – 2″ – 3″ / Steam: 3″ – 4″ |
| Connections | Flanged (ANSI) |
| Max Rating | ANSI 2500 |
| CV | From 0,0055 up to 21,15 |
| Body Material | Cr-Mo alloy steel |
| Trim Material | Stainless steel |
| Max Temperature | 570°C (steam side) |
| NR. of Nozzles | 6 – 9 |
| Rangeability | Up to 50:1 |
| Max Liquid Flow | 50m3/h |
| ΔP | 60 barg (open position) – 80 barg (for HDP version) |
